Actions

An action is what a cell or zone does when dwell finishes (look away, or look at another cell). The same language is used in Page XML, the page editor Action tab, Gazer.exe --action …, and scripts talking back over the named pipe.

This page lists every action type, every value token, and the runtime path each one takes. Command names (toggleLookToScroll, backspace, settings.dwell.fast, …) live on Commands.

When an action runs

1. Gaze stays on a cell through scan grace, then through the activation sequence. Progress fills; the last step repeats while gaze holds.
2. Dwell ends when you look away or at another cell. Blink grace pauses progress; it does not start a new fill.
3. After blink grace expires, the cell fires. The host flashes the cell, then ActionDispatcher runs its actions in document order.
4. Consecutive ShowLayers in that list are collected and applied together (one drawer animation). Any other action flushes the pending layers first, then runs.

Inbound --action payloads skip dwell. They parse into the same action list and run immediately.

Extra switch	What happens
actionLoop="true"	The first fire starts a sticky loop that keeps dispatching the same actions. The next activation of that cell stops it. stopAllActionLoops (and Close All / Close Other) stop every loop.
<Phase> children	The cell no longer has a single-shot list. The first dwell activation enters phase 0. Each later activation advances (the last wraps to the first). The current phase’s actions run when dwell ends. Mixed leftover attributes plus <Phase> is a load error. Empty <Phase/> is a load error.

Unspecified dwell uses rapid timing for Send, modifier commands, mapping keys (backspace, space, enter, …), and compose.backspace / compose.deleteWord. Everything else uses standard (settings, navigation, mouse, AHK, Run, assist toggles, composer word chips). Per-cell scanGrace / activation still override.

How you write an action

A cell or zone may have one action attribute. Several actions use child elements. Attribute names are camelCase; element names are PascalCase. They are the same action.

<Cell row="0" col="0" label="q" send="q"/>
<Cell command="toggleLookToScroll"/>
<Cell openPage="uw_qwerty, true"/>

<Send value="a"/>
<Command value="toggleLookToScroll"/>
<OpenPage value="uw_qwerty, true"/>
<ShowLayers value="1,2"/>
<ClosePage/>
<Speak value="Hello"/>

<Action send="a"/> is the same as <Send value="a"/>. Legacy <Action id="Send" value="a"/> still loads. Old Click / Move / MoveAndClick names still load; the names in the table below are the ones to author.

Command and Run may also take args (<Command value="…" args="…"/>, <Run value="…" args="…"/>). On Run, args is extra process argv. On Command, if value is empty, args becomes the command name.

The page editor Action tab is the same catalog: Type chooses the element; the fields below it are that type’s value.

Catalog

Element / attribute	value	Runtime
Send / send	key[, Down\|Up[, durationMs]]	Keyboard inject (KeyStateManager → Windows SendInput)
Command / command	builtin or mapping name	CommandRegistry: exact builtin, then longest prefix, then default.json
MouseLeftClick / MouseMiddleClick / MouseRightClick	click kind	Click or hold at the current cursor
MouseMoveToGaze	zoom token	Arm dwell-move: next desktop dwell warps the cursor
MouseLeftClickAtGaze / MouseMiddleClickAtGaze / MouseRightClickAtGaze	zoom token	Arm dwell-move, then one click of that button
MouseMoveByDirection	n/s/e/w/ne/nw/se/sw[, px]	Nudge the cursor now
MouseMoveToPoint	[relative,]x,y	Warp (or relative-move) now
OpenPage	targetId[, true]	Attach a catalog page in front
TogglePage	targetId[, true]	Attach if closed; close if that id is already attached
HostPage	fragmentId or hostId, fragmentId	Swap a src slot (no second opaque board)
ShowLayers	layer[, layer…]	Replace the source page’s visible layer set
ClosePage	(empty)	Close the page that owns the cell (the host, if this cell is in a src slot)
CloseAllPages	(empty)	Close every attached page; master root stays. Also disables ComboMouse.
CloseOtherPages	(empty)	Close every attached page except the source page. Also disables ComboMouse.
GoBack	(empty)	Restore the last breadcrumb
Speak	text	Windows SAPI canned utterance
AHK	element body / CDATA	Temp .ahk with a local AutoHotkey install
Run / run	kind,file[,persist][,key]	Spawn a Python or AutoHotkey file

---

Send

Send types a key into the focused OS window (or into the composer phrase when the source page is captured — see Composer capture).

Value

key
key, Down
key, Up
key, durationMs

Part	Meaning
key	What to inject. See Keys.
Down / Up	Hold or release. Case-insensitive.
durationMs	Integer milliseconds. Used only when Edge is omitted: key down now, key up after that many ms. Down / Up ignore duration.

A comma key is send="," (a leading comma is the character, not a separator). Optional edge after that: send=",,Down".

<Cell label="q" send="q"/>
<Cell label="comma" send=","/>
<Cell label="Hold A" send="a,500"/>
<Cell label="Alt down" send="LAlt,Down"/>
<Cell label="Alt up" send="LAlt,Up"/>

What happens

1. Empty key is a no-op.
2. If the source page is a composer capture page, the send is consumed there (Composer capture).
3. Otherwise KeyStateManager runs:
4. Edge omitted, duration 0 — activate: a modifier name cycles Up → Down → LockedDown → Up; any other key is a tap (down+up). After a standard tap, one-shot Down modifiers (not LockedDown) are released so leftShift then send="q" types Q.
5. Down — key down (modifiers enter Down if they were Up).
6. Up — key up.
7. duration > 0, no edge — down now, up after durationMs, then release one-shot modifiers.

US QWERTY punctuation that needs Shift (!, :, ?, …) injects the physical OEM/digit key and a transient Shift when OS Shift is not already held. Letters use the letter virtual-key; whether the OS types q or Q follows the live Shift slot (leftShift / rightShift commands, or a Send of a Shift name).

Failures toast (Send failed or the injector error, for example Unknown key: …).

Dwell: rapid.

Keys

Single character. ASCII letters and digits become those virtual-keys. These US punctuation characters map to a physical key (and extra Shift when the glyph is the shifted one):

Character	Physical key
` ~	Oem3
1 ! … 0 )	1…0
- _	OemMinus
= +	OemPlus
[ {	Oem4
] }	Oem6
; :	Oem1
' "	Oem7
\ |	Oem5
, <	OemComma
. >	OemPeriod
/ ?	Oem2

Any other single character (including non-ASCII) is injected as Unicode SendInput.

Named keys (case-insensitive). These are virtual-keys, not characters:

Names	Key
Back / Backspace	Backspace
Return / Enter	Enter
Tab	Tab
Escape / Esc	Escape
Space	Space
Delete / Del	Delete (extended)
Insert	Insert
Home / End	Home / End
Prior / PageUp	Page Up
Next / PageDown	Page Down
Left / Right / Up / Down	Arrows (extended; Shift+Up stays arrow, not Numpad 8)
F1 … F12	Function keys
Shift / LShift / RShift	Shift
Control / Ctrl / LControl / RControl	Ctrl
Alt / Menu / LMenu / RMenu / LAlt / RAlt	Alt
Win / LWin / RWin	Windows key
Oem1…Oem7, OemMinus, OemPlus, OemComma, OemPeriod (and Oem_… aliases)	OEM keys

Unknown multi-character names fail (Unknown key: …). Prefer mapping commands (command="backspace") for editing keys on keyboards so composer capture can rewrite them.

---

Command

Command looks up a name. It does not type the string.

<Cell icon="keyBackspace" command="backspace"/>
<Cell command="toggleLookToScroll"/>
<Command value="settings.dwell.fast"/>

What happens

1. If the source page is a composer capture page and the name is not in the allow-through families (compose.*, speech.*, soundboard.*, history.*, settings.speech.*, toggleDwellSuspend / suspendDwell / resumeDwell), the command is captured (Composer capture).
2. Otherwise CommandRegistry.run(name, sourcePageId):
3. Exact builtin (shell, assist, settings, composer, …).
4. Else longest prefix handler (settings.edit., compose.removeWord., speech.voice., headPose.map., …).
5. Else mapping profile resources/mappings/default.json next to Gazer.exe. Each mapping name is a list of inject steps (keyTap, gamepadButton, …).
6. Unknown names fail (Command failed: …).
7. Successful builtins toast Cmd <name> except families compose.* / speech.* / soundboard.* / history.* / settings.* / headPose.* / lookTo.*.

Dwell: rapid for mapping keys and modifiers (backspace, leftShift, …). Standard for settings, theme, speech, history, soundboard, compose (except compose.backspace / compose.deleteWord), head-pose, look-to, toggle*, mouse*, cycleMouse*, quitApp, openPageEditor, openPreview, suspendDwell, resumeDwell, stopAllActionLoops.

Names, mapping JSON types, and gamepad.*: Commands.

---

Mouse clicks at the cursor

MouseLeftClick, MouseMiddleClick, MouseRightClick act at the current pointer. They do not wait for a second dwell.

value	Also accepted	What happens
(empty) / default / single		One click. Marks that button released in the mouse-pad hold state.
double		Double-click. Marks released.
down		Button down (hold).
up		Button up.
toggle		Flip hold: down if that button is up, up if it is down. activeState="mouse.leftHold" (or .rightHold / .middleHold) paints the cell on.

<Cell label="Left" mouseLeftClick=""/>
<Cell label="L×2" mouseLeftClick="double"/>
<Cell label="L Hold" activeState="mouse.leftHold" mouseLeftClick="toggle"/>

Dwell: standard.

---

Move to gaze and click-at-gaze

These arm dwell-move. The cell itself does not click the desktop. The next time you dwell a point outside Gazer chrome, the cursor warps there (and click-at-gaze then clicks).

Arming again while that purpose is already armed cancels it.

Action	After the warp
MouseMoveToGaze	Cursor sits there
MouseLeftClickAtGaze / Middle / Right	One click of that button

Zoom value

Token	What happens
(empty) / default	Follow Settings → Zoom (mag-pick on/off, foresight, zoom).
0	Dwell-move with no magnify window.
2 … 6 (any positive integer)	Force that zoom factor for this arm.
-1	Foresight: remember a desktop dwell, then zoom that point when Move-to arms.
-2	Foresight plus the bonus second zoom.

<Cell label="Move" mouseMoveToGaze=""/>
<Cell label="Move+L" activeState="mouseLeftClickAtGaze" mouseLeftClickAtGaze=""/>
<Cell label="Pick 4×" mouseLeftClickAtGaze="4"/>
<Cell label="No mag" mouseMoveToGaze="0"/>

mouseMoveToGaze as a command is the same arm (toggle). Click-at-gaze commands (mouseLeftClickAtGaze, …) exist too; XML actions let you pin zoom per cell.

Dwell: standard.

---

Nudge and warp now

MouseMoveByDirection

value	What happens
n s e w ne nw se sw	Move by the mouse-assist step (Settings / cycleMouseMoveAmount).
se,40	Same compass, 40 px this time.

Compass tokens are the same as grid anchors (Top = n, BottomRight = se, …).

MouseMoveToPoint

value	What happens
x,y	Warp to that point. x and y are dim tokens: pixels (100), proportions (0.5), A_ScreenWidth / A_ScreenHeight arithmetic, clamp(...).
relative,x,y	Move by those amounts (same dim tokens, resolved against the virtual desktop / current screen).

<Cell label="Up" mouseMoveByDirection="n"/>
<Cell label="Home" mouseMoveToPoint="0.5,0.5"/>

Dwell: standard.

---

Page navigation

Attached pages stack newest in front on the same host window. The master root (main) never destroys itself.

OpenPage

value: catalogId or catalogId, true.

• Loads that catalog id (filename stem; %AppData%\Gazer\layouts overrides shipped XML).
• Attaches it in front. Opening the root id raises the host instead of stacking a second root.
• Second field true / false (required if present) snapshots a breadcrumb of the current stack and layers so GoBack can restore it.

TogglePage

Same value as OpenPage. If that id is already attached, it closes; otherwise it opens.

ClosePage

No value. Closes the page that owns the cell. If that page is a fragment sitting in a src slot, the host board closes instead. Closing the root is rejected (the host is raised).

CloseAllPages / CloseOtherPages

No value. Close All drops every attached page. Close Other keeps the source page. Both disable ComboMouse.

GoBack

No value. Restores the last breadcrumb. Fails with a toast if the stack is empty.

HostPage

value: fragmentId or hostId, fragmentId.

• Finds a grid with src="…" on the host (the source page when hostId is omitted, or the stack page that embeds that source; or the named catalog page, attaching it if needed).
• Sets the slot to fragmentId and rebuilds. The fragment’s cells keep the fragment page id as their live target (main_settings_dwell/dwell_edit).
• Settings uses this to swap Dwell, Zoom, Place, Gaze, Head, Speak, Theme, and Setup into one frame. It does not stack a second opaque page.

<Cell label="Keyboard" openPage="qwerty_main"/>
<Cell label="Wide" openPage="uw_qwerty, true"/>
<Cell label="Dwell" hostPage="main_settings_host, main_settings_dwell"/>
<Cell label="Zoom" hostPage="main_settings_host, main_settings_zoom"/>
<Cell label="Done" closePage="true"/>
<GoBack/>

closePage="true" is an attribute form of ClosePage (the token is ignored).

Dwell: standard.

---

ShowLayers

value: comma-separated layer numbers (1, 1,2, 1,3). Replaces the source page’s visible set. A grid or zone is shown when any of its layers membership is in that set. Default both sides: 1.

Typical master page: 1 dock chips, 2 drawer, 3 quit. Keyboard shift/symbol boards are extra layers on the same page.

Several ShowLayers in one cell are applied together, then the drawer animates: appear when a drawerMotion grid is shown, dismiss when it is the last master grid hidden, snap when another master grid remains.

If the source page just closed in this same activation (ClosePage then ShowLayers), layers apply to the root.

Inbound: after OpenPage in the same payload, ShowLayers applies to the page that just opened (the dispatcher updates the source to the new top).

<ShowLayers value="1,2"/>
<Cell label="Dismiss" showLayers="1"/>

Dwell: standard.

---

Speak

value is the utterance. Always Windows SAPI (SpeakKind::Canned). Composer synthesis (ElevenLabs or SAPI from Settings → Speak) is compose.speak.

Empty text still calls speak; non-empty text toasts Said: ….

Dwell: standard.

---

AHK (inline)

Element body only (<AHK>…</AHK>). The source is written to a temp .ahk and started with a local AutoHotkey install (v2 preferred). A first line #Requires AutoHotkey v1 selects v1. GAZER_AHK points at an exe to override discovery. AutoHotkey is not bundled.

<Cell label="MID" icon="WindowMid">
  <AHK><![CDATA[
  {
  try {
    Title := WinGetTitle("A")
    WinRestore Title
    WinMove -4, -4, 15/16*A_ScreenWidth+8, 0.73*(A_ScreenHeight-32), Title
  } catch {
  }
  }
  ]]></AHK>
</Cell>

Dwell: standard. Talk back with Gazer.exe --action …. The pipe is Qt duplex; FileOpen write-only is unreliable.

---

Run (Python / AHK files)

value: kind,file[,persist][,key]

Field	Options
kind	python / py or ahk / autohotkey
file	Path to a .py or .ahk file
persist	persist or true / false. Persist starts once (until Gazer quits).
key	Identity for persist (default: the file path)

args is extra argv (<Run value="python,scripts/predict.py" args="--once"/>).

Relative file is resolved in order: the page directory, %AppData%\Gazer, the app resources folder. Absolute paths must stay under those roots.

Python is not bundled (python / python3 / py -3 on PATH, or GAZER_PYTHON). Working directory is the script folder. Children see GAZER_EXE and GAZER_ACTION_PIPE.

<Cell label="Predict">
  <Run value="python,scripts/predict.py,persist,predict"/>
</Cell>
<Cell label="Snap" run="ahk,scripts/snap.ahk"/>

Dwell: standard.

---

Multiple actions and phases

<Cell label="Close All" icon="CloseAll">
  <CloseAllPages/>
  <ShowLayers value="1,2"/>
</Cell>

<Cell id="chip_0" row="0" col="0">
  <Phase command="compose.moveEndOfWord.0"/>
  <Phase command="compose.removeWord.0"/>
</Cell>

Composer word chips use phases: first dwell moves the caret to that word; a later dwell deletes it. After an activation, progress holds full through scan grace before the next step clocks.

---

Composer capture

While the action’s source page is compose, compose_voices_live, compose_history_live, or compose_item_edit_live:

Incoming	What happens
Send of a single character	Inserted into the phrase (only when compose is top, or while renaming an item).
Send of space (named)	Inserts a space in those same cases. Other named Send keys are consumed and ignored.
command="backspace" / compose.backspace	Deletes in the buffer.
command="space"	Inserts a space.
command="enter"	Speaks (or saves, while renaming).
command="escape"	Stops speech if busy; otherwise cancels assign/edit, closes a live overlay, or closes composer.
leftShift, tab, arrows, other mapping keys	Consumed, no OS inject.
compose.* / speech.* / soundboard.* / history.* / settings.speech.* / dwell suspend commands	Run as builtins (not captured).

qwerty_main (and any other non-compose page) still injects into Windows even if composer is open underneath. Caps on the composer keyboard is XML ShowLayers, not OS Shift.

---

Inbound CLI and the pipe

The live process listens on a same-user named pipe Gazer (\\.\pipe\Gazer; override with GAZER_ACTION_PIPE). A second Gazer.exe with --action forwards to that pipe and exits. Several --action flags run in order (joined as lines).

Payload forms:

Form	Example
name=value	command=toggleLookToScroll
name value	speak Hello there
XML elements	<OpenPage value="qwerty_main"/><ShowLayers value="2"/>
# comment / empty lines	ignored
raise (or a second exe with no --action)	Bring the host to front
--editor on a second instance	Also queues command=openPageEditor

Gazer.exe --action openPage=qwerty_main --action showLayers=2
Gazer.exe --action command=toggleLookToScroll
Gazer.exe --action "<Speak value=\"Hello\"/>"
Gazer.exe --action run=python,scripts/predict.py

Empty pipe reads are ignored (a liveness probe is not a command). <Phase> is not valid inbound.

After OpenPage in one payload, later ShowLayers apply to the opened page.

---

Editor fields

Tray → Page editor → select a cell → Action. Type is the catalog above. Extra fields:

Type	Fields
Send	Key, Edge (Down / Up / empty), Hold ms
Command	Name (combo of builtins + mapping), Args
Click	default / double / down / up / toggle
Move to gaze / click-at-gaze	Zoom (default, 0, −1, −2, 2…6)
Move by direction	Compass, Amount px (−1 = Settings step)
Move to point	X, Y dims
Open / Toggle	Target catalog id, Save breadcrumb
HostPage	Host page ((this page) or an id), Body page
ShowLayers	Layer csv
Speak	Text
AHK	Script body
Run	Kind, File, Keep running, Key, Args
Loop	Loop until activated again (actionLoop)

Empty actions warn before Save and F5.

Schema in the repo: docs/page-xml.md. Shipped examples: resources/layouts/main.xml, example_keyboard.xml, example_mouse.xml, example_gamepad.xml, compose.xml.
